Plastic Series Open type TKP Series/TKP Series MW Type/TKP Series Gliding arrangement/TKP Series Circular travel arrangement

Link
Shortening/lengthening

A standard Cable Carrier (CABLEVEYOR) with a wide range of sizes from small to large.
- It is the most widely used and easy to handle.
Gliding arrangement specifications, circular travel arrangement, and a wide range of other special specifications are available.
- The MW specification is made of a low-friction material, which is effective in preventing wear on the outer coating of cables and hoses.

Features

TKP Series

A wide range of sizes available

We have a lineup of 16 types ranging from small to large sizes.
Made of plastic, lightweight and economical
Easy to cut and connect

The simple connecting structure of inserting a pin into a hole makes cutting and connecting easy.
Supports multi-level partitions

TKP35H22 to TKP125H74 (excluding some sizes) allow the storage space to be divided into multiple levels, improving layout flexibility.
Steel mounting brackets can be replaced with stainless steel ones
Maintaining quality while adding environmental friendliness

Some sizes of TKP series are made from environmentally friendly recycled materials, while maintaining the same performance, dimensions, and appearance as before.
This allows for more environmentally friendly manufacturing.

TKP Series MW specifications

Low dust generation

Compared to the TKP type, there is less wear debris generated by the sliding of Cable Carrier (CABLEVEYOR) and the cable/hose, as well as wear debris generated by the sliding of Cable Carrier (CABLEVEYOR) connection parts.
The approximate dimensions and structure are the same as the TKP type.

Special specifications

TKP Series Gliding arrangement specification

This is a method of use in which Cable Carrier (CABLEVEYOR) slides on guide channel when a long stroke exceeding the free span on Allowable load graph is required.
- By installing sliding shoe, it achieves a long life and labor savings with Long travel length and high speed movement.

It contributes to reducing total costs and environmental impact by reducing running costs.

TKP Series circular travel arrangement

-Can be used for equipment that rotates.
・Standard products cannot be used. They are specially manufactured products.

Click here for detailed specifications

For other special specifications, please see here.

Catalogs and Instruction Manuals

Product List

*Click to display detailed information. Open all Close all

Cable/hose maximum outer diameter: 4mm, 7mm, 8mm (TKP13~, TKP17~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
28	TKP13H10-20W6R28	TKP13H10-30W6R28
37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
20	TKP13H10-20W10R20	---	---
28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
28	TKP13H10-20W15R28	TKP13H10-30W15R28
37	TKP13H10-20W15R37	TKP13H10-30W15R37
20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
20	TKP13H10-20W20R20	---	---
28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

Cable/hose maximum outer diameter: 11mm, 12mm, 13mm, 14mm, 20mm (TKP18~, TKP25~, TKP35~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
11	35	22	13	37	---	TKP35H22-30W13R37	TKP35H22-30W13R37M	---	TKP35H22-40W13R37	TKP35H22-40W13R37M	---	---	---
50	TKP35H22-30W13R50	TKP35H22-30W13R50M	TKP35H22-40W13R50	TKP35H22-40W13R50M
75	TKP35H22-30W13R75	TKP35H22-30W13R75M	TKP35H22-40W13R75	TKP35H22-40W13R75M
100	TKP35H22-30W13R100	TKP35H22-30W13R100M	TKP35H22-40W13R100	TKP35H22-40W13R100M
12	18	14	15	28	---	TKP18H14-30W15R28TC	TKP18H14-30W15R28M	---	---	---	---	---	---
37	TKP18H14-30W15R37TC	TKP18H14-30W15R37M
50	TKP18H14-30W15R50TC	TKP18H14-30W15R50M
40	28	---	TKP18H14-30W40R28TC	TKP18H14-30W40R28M	---	---	---	---	---	---
37	TKP18H14-30W40R37TC	TKP18H14-30W40R37M
50	TKP18H14-30W40R50TC	TKP18H14-30W40R50M
13	15	15	28	TKP18H15-20W15R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W15R37
50	TKP18H15-20W15R50
20	28	TKP18H15-20W20R28	TKP18H15-30W20R28	---	---	---	---	---	---	---
37	TKP18H15-20W20R37	TKP18H15-30W20R37
50	TKP18H15-20W20R50	TKP18H15-30W20R50
30	28	TKP18H15-20W30R28	TKP18H15-30W30R28	---	---	---	---	---	---	---
37	TKP18H15-20W30R37	TKP18H15-30W30R37
50	TKP18H15-20W30R50	TKP18H15-30W30R50
40	28	TKP18H15-20W40R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W40R37
50	TKP18H15-20W40R50
25	15	15	28	---	TKP25H15-30W15R28	TKP25H15-30W15R28M	---	---	---	---	---	---
37	TKP25H15-30W15R37	TKP25H15-30W15R37M
50	TKP25H15-30W15R50	TKP25H15-30W15R50M
20	28	---	TKP25H15-30W20R28	TKP25H15-30W20R28M	---	---	---	---	---	---
37	TKP25H15-30W20R37	TKP25H15-30W20R37M
50	TKP25H15-30W20R50	TKP25H15-30W20R50M
30	28	---	TKP25H15-30W30R28	TKP25H15-30W30R28M	---	---	---	---	---	---
37	TKP25H15-30W30R37	TKP25H15-30W30R37M
50	TKP25H15-30W30R50	TKP25H15-30W30R50M
14	35	32	16	48	---	TKP35H32-30W16R48	---	---	---	---	---	---	---
60	TKP35H32-30W16R60	TKP35H32-30W16R60M
75	TKP35H32-30W16R75	TKP35H32-30W16R75M
100	TKP35H32-30W16R100	TKP35H32-30W16R100M
125	TKP35H32-30W16R125	TKP35H32-30W16R125M
20	35	22	25	37	---	TKP35H22-30W25R37	TKP35H22-30W25R37M	TKP35H22-30W25R37	TKP35H22-40W25R37	TKP35H22-40W25R37M	---	---	---
50	TKP35H22-30W25R50	TKP35H22-30W25R50M	TKP35H22-30W25R50	TKP35H22-40W25R50	TKP35H22-40W25R50M
75	TKP35H22-30W25R75	TKP35H22-30W25R75M	TKP35H22-30W25R75	TKP35H22-40W25R75	TKP35H22-40W25R75M
100	TKP35H22-30W25R100	TKP35H22-30W25R100M	TKP35H22-30W25R100	TKP35H22-40W25R100	TKP35H22-40W25R100M
38	37	---	TKP35H22-30W38R37	TKP35H22-30W38R37M	TKP35H22-30W38R37	TKP35H22-40W38R37	TKP35H22-40W38R37M	---	---	---
50	TKP35H22-30W38R50	TKP35H22-30W38R50M	TKP35H22-30W38R50	TKP35H22-40W38R50	TKP35H22-40W38R50M
75	TKP35H22-30W38R75	TKP35H22-30W38R75M	TKP35H22-30W38R75	TKP35H22-40W38R75	TKP35H22-40W38R75M
100	TKP35H22-30W38R100	TKP35H22-30W38R100M	TKP35H22-30W38R100	TKP35H22-40W38R100	TKP35H22-40W38R100M
50	37	---	TKP35H22-30W50R37	TKP35H22-30W50R37M	TKP35H22-30W50R37	TKP35H22-40W50R37	TKP35H22-40W50R37M	---	---	---
50	TKP35H22-30W50R50	TKP35H22-30W50R50M	TKP35H22-30W50R50	TKP35H22-40W50R50	TKP35H22-40W50R50M
75	TKP35H22-30W50R75	TKP35H22-30W50R75M	TKP35H22-30W50R75	TKP35H22-40W50R75	TKP35H22-40W50R75M
100	TKP35H22-30W50R100	TKP35H22-30W50R100M	TKP35H22-30W50R100	TKP35H22-40W50R100	TKP35H22-40W50R100M
63	37	---	TKP35H22-30W63R37	TKP35H22-30W63R37M	TKP35H22-30W63R37	TKP35H22-40W63R37	TKP35H22-40W63R37M	---	---	---
50	TKP35H22-30W63R50	TKP35H22-30W63R50M	TKP35H22-30W63R50	TKP35H22-40W63R50	TKP35H22-40W63R50M
75	TKP35H22-30W63R75	TKP35H22-30W63R75M	TKP35H22-30W63R75	TKP35H22-40W63R75	TKP35H22-40W63R75M
100	TKP35H22-30W63R100	TKP35H22-30W63R100M	TKP35H22-30W63R100	TKP35H22-40W63R100	TKP35H22-40W63R100M

Cable/hose maximum outer diameter: 22mm, 29mm (TKP35~, TKP45~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
22	45	25	38	50	---	TKP45H25-30W38R50	TKP45H25-30W38R50M	TKP45H25-30W38R50	TKP45H25-40W38R50	TKP45H25-40W38R50M	---	---	---
75	TKP45H25-30W38R75	TKP45H25-30W38R75M	TKP45H25-30W38R75	TKP45H25-40W38R75	TKP45H25-40W38R75M
95	TKP45H25-30W38R95	TKP45H25-30W38R95M	TKP45H25-30W38R95	TKP45H25-40W38R95	TKP45H25-40W38R95M
125	TKP45H25-30W38R125	TKP45H25-30W38R125M	TKP45H25-30W38R125	TKP45H25-40W38R125	TKP45H25-40W38R125M
150	TKP45H25-30W38R150	TKP45H25-30W38R150M	TKP45H25-30W38R150	TKP45H25-40W38R150	TKP45H25-40W38R150M
200	TKP45H25-30W38R200	TKP45H25-30W38R200M	TKP45H25-30W38R200	TKP45H25-40W38R200	TKP45H25-40W38R200M
58	50	---	TKP45H25-30W58R50	TKP45H25-30W58R50M	TKP45H25-30W58R50	TKP45H25-40W58R50	TKP45H25-40W58R50M	---	---	---
75	TKP45H25-30W58R75	TKP45H25-30W58R75M	TKP45H25-30W58R75	TKP45H25-40W58R75	TKP45H25-40W58R75M
95	TKP45H25-30W58R95	TKP45H25-30W58R95M	TKP45H25-30W58R95	TKP45H25-40W58R95	TKP45H25-40W58R95M
125	TKP45H25-30W58R125	TKP45H25-30W58R125M	TKP45H25-30W58R125	TKP45H25-40W58R125	TKP45H25-40W58R125M
150	TKP45H25-30W58R150	TKP45H25-30W58R150M	TKP45H25-30W58R150	TKP45H25-40W58R150	TKP45H25-40W58R150M
200	TKP45H25-30W58R200	TKP45H25-30W58R200M	TKP45H25-30W58R200	TKP45H25-40W58R200	TKP45H25-40W58R200M
78	50	---	TKP45H25-30W78R50	TKP45H25-30W78R50M	TKP45H25-30W78R50	TKP45H25-40W78R50	TKP45H25-40W78R50M	---	---	---
75	TKP45H25-30W78R75	TKP45H25-30W78R75M	TKP45H25-30W78R75	TKP45H25-40W78R75	TKP45H25-40W78R75M
95	TKP45H25-30W78R95	TKP45H25-30W78R95M	TKP45H25-30W78R95	TKP45H25-40W78R95	TKP45H25-40W78R95M
125	TKP45H25-30W78R125	TKP45H25-30W78R125M	TKP45H25-30W78R125	TKP45H25-40W78R125	TKP45H25-40W78R125M
150	TKP45H25-30W78R150	TKP45H25-30W78R150M	TKP45H25-30W78R150	TKP45H25-40W78R150	TKP45H25-40W78R150M
200	TKP45H25-30W78R200	TKP45H25-30W78R200M	TKP45H25-30W78R200	TKP45H25-40W78R200	TKP45H25-40W78R200M
103	50	---	TKP45H25-30W103R50	TKP45H25-30W103R50M	TKP45H25-30W103R50	TKP45H25-40W103R50	TKP45H25-40W103R50M	---	---	---
75	TKP45H25-30W103R75	TKP45H25-30W103R75M	TKP45H25-30W103R75	TKP45H25-40W103R75	TKP45H25-40W103R75M
95	TKP45H25-30W103R95	TKP45H25-30W103R95M	TKP45H25-30W103R95	TKP45H25-40W103R95	TKP45H25-40W103R95M
125	TKP45H25-30W103R125	TKP45H25-30W103R125M	TKP45H25-30W103R125	TKP45H25-40W103R125	TKP45H25-40W103R125M
150	TKP45H25-30W103R150	TKP45H25-30W103R150M	TKP45H25-30W103R150	TKP45H25-40W103R150	TKP45H25-40W103R150M
200	TKP45H25-30W103R200	TKP45H25-30W103R200M	TKP45H25-30W103R200	TKP45H25-40W103R200	TKP45H25-40W103R200M
35	32	25	48	---	TKP35H32-30W25R48	---	---	TKP35H32-40W25R48	---	---	---	---
60	TKP35H32-30W25R60	TKP35H32-40W25R60
75	TKP35H32-30W25R75	TKP35H32-40W25R75
100	TKP35H32-30W25R100	TKP35H32-40W25R100
125	TKP35H32-30W25R125	TKP35H32-40W25R125
29	35	32	38	48	---	TKP35H32-30W38R48	---	---	TKP35H32-40W38R48	---	---	---	---
60	TKP35H32-30W38R60	TKP35H32-40W38R60
75	TKP35H32-30W38R75	TKP35H32-40W38R75
100	TKP35H32-30W38R100	TKP35H32-40W38R100
125	TKP35H32-30W38R125	TKP35H32-40W38R125
50	48	---	TKP35H32-30W50R48	---	---	TKP35H32-40W50R48	---	---	---	---
60	TKP35H32-30W50R60	TKP35H32-40W50R60
75	TKP35H32-30W50R75	TKP35H32-40W50R75
100	TKP35H32-30W50R100	TKP35H32-40W50R100
125	TKP35H32-30W50R125	TKP35H32-40W50R125

Cable/hose maximum outer diameter: 30mm, 35mm (TKP58~, TKP62~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
30	62.5	34	150	75	---	---	---	---	---	---	---	TKP62H34W150R75	TKP62H34W150R75
90	TKP62H34W150R90	TKP62H34W150R90
125	TKP62H34W150R125	TKP62H34W150R125
150	TKP62H34W150R150	TKP62H34W150R150
200	TKP62H34W150R200	TKP62H34W150R200
200	75	---	---	---	---	---	---	---	TKP62H34W200R75	TKP62H34W200R75
90	TKP62H34W200R90	TKP62H34W200R90
125	TKP62H34W200R125	TKP62H34W200R125
150	TKP62H34W200R150	TKP62H34W200R150
200	TKP62H34W200R200	TKP62H34W200R200
35	58	39	50	60	---	TKP58H39-30W50R60	---	TKP58H39-30W50R60	TKP58H39-40W50R60	---	---	---	---
75	TKP58H39-30W50R75	TKP58H39-30W50R75	TKP58H39-40W50R75
90	TKP58H39-30W50R90	TKP58H39-30W50R90	TKP58H39-40W50R90
125	TKP58H39-30W50R125	TKP58H39-30W50R125	TKP58H39-40W50R125
150	TKP58H39-30W50R150	TKP58H39-30W50R150	TKP58H39-40W50R150
200	TKP58H39-30W50R200	TKP58H39-30W50R200	TKP58H39-40W50R200
75	60	---	TKP58H39-30W75R60	---	TKP58H39-30W75R60	TKP58H39-40W75R60	---	---	---	---
75	TKP58H39-30W75R75	TKP58H39-30W75R75	TKP58H39-40W75R75
90	TKP58H39-30W75R90	TKP58H39-30W75R90	TKP58H39-40W75R90
125	TKP58H39-30W75R125	TKP58H39-30W75R125	TKP58H39-40W75R125
150	TKP58H39-30W75R150	TKP58H39-30W75R150	TKP58H39-40W75R150
200	TKP58H39-30W75R200	TKP58H39-30W75R200	TKP58H39-40W75R200
100	60	---	TKP58H39-30W100R60	---	TKP58H39-30W100R60	TKP58H39-40W100R60	---	---	---	---
75	TKP58H39-30W100R75	TKP58H39-30W100R75	TKP58H39-40W100R75
90	TKP58H39-30W100R90	TKP58H39-30W100R90	TKP58H39-40W100R90
125	TKP58H39-30W100R125	TKP58H39-30W100R125	TKP58H39-40W100R125
150	TKP58H39-30W100R150	TKP58H39-30W100R150	TKP58H39-40W100R150
200	TKP58H39-30W100R200	TKP58H39-30W100R200	TKP58H39-40W100R200
125	60	---	TKP58H39-30W125R60	---	TKP58H39-30W125R60	TKP58H39-40W125R60	---	---	---	---
75	TKP58H39-30W125R75	TKP58H39-30W125R75	TKP58H39-40W125R75
90	TKP58H39-30W125R90	TKP58H39-30W125R90	TKP58H39-40W125R90
125	TKP58H39-30W125R125	TKP58H39-30W125R125	TKP58H39-40W125R125
150	TKP58H39-30W125R150	TKP58H39-30W125R150	TKP58H39-40W125R150
200	TKP58H39-30W125R200	TKP58H39-30W125R200	TKP58H39-40W125R200

Cable/hose maximum outer diameter: 41mm, 45mm (TKP68~, TKP90~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
41	68	46	75	75	---	TKP68H46-30W75R75	---	TKP68H46-30W75R75	TKP68H46-40W75R75	---	---	---	---
100	TKP68H46-30W75R100	TKP68H46-30W75R100	TKP68H46-40W75R100
125	TKP68H46-30W75R125	TKP68H46-30W75R125	TKP68H46-40W75R125
150	TKP68H46-30W75R150	TKP68H46-30W75R150	TKP68H46-40W75R150
200	TKP68H46-30W75R200	TKP68H46-30W75R200	TKP68H46-40W75R200
250	TKP68H46-30W75R250	TKP68H46-30W75R250	TKP68H46-40W75R250
100	75	---	TKP68H46-30W100R75	---	TKP68H46-30W100R75	TKP68H46-40W100R75	---	---	---	---
100	TKP68H46-30W100R100	TKP68H46-30W100R100	TKP68H46-40W100R100
125	TKP68H46-30W100R125	TKP68H46-30W100R125	TKP68H46-40W100R125
150	TKP68H46-30W100R150	TKP68H46-30W100R150	TKP68H46-40W100R150
200	TKP68H46-30W100R200	TKP68H46-30W100R200	TKP68H46-40W100R200
250	TKP68H46-30W100R250	TKP68H46-30W100R250	TKP68H46-40W100R250
125	75	---	TKP68H46-30W125R75	---	TKP68H46-30W125R75	TKP68H46-40W125R75	---	---	---	---
100	TKP68H46-30W125R100	TKP68H46-30W125R100	TKP68H46-40W125R100
125	TKP68H46-30W125R125	TKP68H46-30W125R125	TKP68H46-40W125R125
150	TKP68H46-30W125R150	TKP68H46-30W125R150	TKP68H46-40W125R150
200	TKP68H46-30W125R200	TKP68H46-30W125R200	TKP68H46-40W125R200
250	TKP68H46-30W125R250	TKP68H46-30W125R250	TKP68H46-40W125R250
150	75	---	TKP68H46-30W150R75	---	TKP68H46-30W150R75	TKP68H46-40W150R75	---	---	---	---
100	TKP68H46-30W150R100	TKP68H46-30W150R100	TKP68H46-40W150R100
125	TKP68H46-30W150R125	TKP68H46-30W150R125	TKP68H46-40W150R125
150	TKP68H46-30W150R150	TKP68H46-30W150R150	TKP68H46-40W150R150
200	TKP68H46-30W150R200	TKP68H46-30W150R200	TKP68H46-40W150R200
250	TKP68H46-30W150R250	TKP68H46-30W150R250	TKP68H46-40W150R250
175	75	---	TKP68H46-30W175R75	---	TKP68H46-30W175R75	TKP68H46-40W175R75	---	---	---	---
100	TKP68H46-30W175R100	TKP68H46-30W175R100	TKP68H46-40W175R100
125	TKP68H46-30W175R125	TKP68H46-30W175R125	TKP68H46-40W175R125
150	TKP68H46-30W175R150	TKP68H46-30W175R150	TKP68H46-40W175R150
200	TKP68H46-30W175R200	TKP68H46-30W175R200	TKP68H46-40W175R200
250	TKP68H46-30W175R250	TKP68H46-30W175R250	TKP68H46-40W175R250
45	90	50	100	130	---	---	---	---	---	---	---	TKP90H50W100R130	TKP90H50W100R130
200	TKP90H50W100R200	TKP90H50W100R200
250	TKP90H50W100R250	TKP90H50W100R250
300	TKP90H50W100R300	---
150	130	---	---	---	---	---	---	---	TKP90H50W150R130	TKP90H50W150R130
200	TKP90H50W150R200	TKP90H50W150R200
250	TKP90H50W150R250	TKP90H50W150R250
300	TKP90H50W150R300	---
200	130	---	---	---	---	---	---	---	TKP90H50W200R130	TKP90H50W200R130
200	TKP90H50W200R200	TKP90H50W200R200
250	TKP90H50W200R250	TKP90H50W200R250
300	TKP90H50W200R300	---

Cable/hose maximum outer diameter 50mm (TKP91H56~)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
50	91	56	150	150	---	---	---	---	---	---	---	TKP91H56W150R150	---
200	TKP91H56W150R200	TKP91H56W150R200-GA
250	TKP91H56W150R250	TKP91H56W150R250-GA
300	TKP91H56W150R300	TKP91H56W150R300-GA
350	TKP91H56W150R350	---
400	TKP91H56W150R400	---
175	150	---	---	---	---	---	---	---	TKP91H56W175R150	---
200	TKP91H56W175R200	TKP91H56W175R200-GA
250	TKP91H56W175R250	TKP91H56W175R250-GA
300	TKP91H56W175R300	TKP91H56W175R300-GA
350	TKP91H56W175R350	---
400	TKP91H56W175R400	---
200	150	---	---	---	---	---	---	---	TKP91H56W200R150	---
200	TKP91H56W200R200	TKP91H56W200R200-GA
250	TKP91H56W200R250	TKP91H56W200R250-GA
300	TKP91H56W200R300	TKP91H56W200R300-GA
350	TKP91H56W200R350	---
400	TKP91H56W200R400	---
225	150	---	---	---	---	---	---	---	TKP91H56W225R150	---
200	TKP91H56W225R200	TKP91H56W225R200-GA
250	TKP91H56W225R250	TKP91H56W225R250-GA
300	TKP91H56W225R300	TKP91H56W225R300-GA
350	TKP91H56W225R350	---
400	TKP91H56W225R400	---
250	150	---	---	---	---	---	---	---	TKP91H56W250R150	---
200	TKP91H56W250R200	TKP91H56W250R200-GA
250	TKP91H56W250R250	TKP91H56W250R250-GA
300	TKP91H56W250R300	TKP91H56W250R300-GA
350	TKP91H56W250R350	---
400	TKP91H56W250R400	---
275	150	---	---	---	---	---	---	---	TKP91H56W275R150	---
200	TKP91H56W275R200	TKP91H56W275R200-GA
250	TKP91H56W275R250	TKP91H56W275R250-GA
300	TKP91H56W275R300	TKP91H56W275R300-GA
350	TKP91H56W275R350	---
400	TKP91H56W275R400	---
300	150	---	---	---	---	---	---	---	TKP91H56W300R150	---
200	TKP91H56W300R200	TKP91H56W300R200-GA
250	TKP91H56W300R250	TKP91H56W300R250-GA
300	TKP91H56W300R300	TKP91H56W300R300-GA
350	TKP91H56W300R350	---
400	TKP91H56W300R400	---
325	150	---	---	---	---	---	---	---	TKP91H56W325R150	---
200	TKP91H56W325R200	TKP91H56W325R200-GA
250	TKP91H56W325R250	TKP91H56W325R250-GA
300	TKP91H56W325R300	TKP91H56W325R300-GA
350	TKP91H56W325R350	---
400	TKP91H56W325R400	---
350	150	---	---	---	---	---	---	---	TKP91H56W350R150	---
200	TKP91H56W350R200	TKP91H56W350R200-GA
250	TKP91H56W350R250	TKP91H56W350R250-GA
300	TKP91H56W350R300	TKP91H56W350R300-GA
350	TKP91H56W350R350	---
400	TKP91H56W350R400	---
400	150	---	---	---	---	---	---	---	TKP91H56W400R150	---
200	TKP91H56W400R200	TKP91H56W400R200-GA
250	TKP91H56W400R250	TKP91H56W400R250-GA
300	TKP91H56W400R300	TKP91H56W400R300-GA
350	TKP91H56W400R350	---
400	TKP91H56W400R400	---
450	150	---	---	---	---	---	---	---	TKP91H56W450R150	---
200	TKP91H56W450R200	TKP91H56W450R200-GA
250	TKP91H56W450R250	TKP91H56W450R250-GA
300	TKP91H56W450R300	TKP91H56W450R300-GA
350	TKP91H56W450R350	---
400	TKP91H56W450R400	---
500	150	---	---	---	---	---	---	---	TKP91H56W500R150	---
200	TKP91H56W500R200	TKP91H56W500R200-GA
250	TKP91H56W500R250	TKP91H56W500R250-GA
300	TKP91H56W500R300	TKP91H56W500R300-GA
350	TKP91H56W500R350	---
400	TKP91H56W500R400	---

Cable/hose maximum outer diameter 67mm (TKP125 and above)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
67	125	74	150	185	---	---	---	---	---	---	---	TKP125H74W150R185	TKP125H74W150R185
250	TKP125H74W150R250	TKP125H74W150R250
350	TKP125H74W150R350	TKP125H74W150R350
450	TKP125H74W150R450	---
250	185	---	---	---	---	---	---	---	TKP125H74W250R185	TKP125H74W250R185
250	TKP125H74W250R250	TKP125H74W250R250
350	TKP125H74W250R350	TKP125H74W250R350
450	TKP125H74W250R450	---
350	185	---	---	---	---	---	---	---	TKP125H74W350R185	TKP125H74W350R185
250	TKP125H74W350R250	TKP125H74W350R250
350	TKP125H74W350R350	TKP125H74W350R350
450	TKP125H74W350R450	---

Cable/hose maximum outer diameter 72mm (TKP91H80 and above)

Cables ・Hose Maximum Outer Diameter mm	Pitch mm	Inner Height mm	Inner width mm	bending radius mm	Stay openable structure
					Single-part frame type	Outside openable stay type			Arm inner circumference opening and closing type			Inside/outside openable stay type
					Single-part frame type	Standard Specifications	MW specification	Gliding arrangement	Standard Specifications	MW specification	Gliding arrangement	Standard Specifications	Gliding arrangement
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
				28	TKP13H10-20W6R28	TKP13H10-30W6R28
				37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
				20	TKP13H10-20W10R20	---	---
				28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
				37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
			15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
				28	TKP13H10-20W15R28	TKP13H10-30W15R28
				37	TKP13H10-20W15R37	TKP13H10-30W15R37
			20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
				20	TKP13H10-20W20R20	---	---
				28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
				37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

TSUBAKI Power Transmission Products Information Site

Plastic Series Open type TKP Series/TKP Series MW Type/TKP Series Gliding arrangement/TKP Series Circular travel arrangement

Features

TKP Series

TKP Series MW specifications

Special specifications

TKP Series Gliding arrangement specification

TKP Series circular travel arrangement

Catalogs and Instruction Manuals

Product List
