Plastic modular chain WTU3015T-K/WTU3015T-K-SUSP type
- チェーンピッチ
30mm - For curved transport
- Closed type
- WTU3010 Series Plastic modular chain for Curved Conveyance
- Conveyance in a variety of layouts is possible, including curved conveyance at 90 degrees, 180 degrees, and S-curves.
- It can transport cardboard boxes, suitcases, trays and beverage containers.
Features
- -Plastic modular chain are characterized by their ease of maintenance and the ability to prevent scratches on transported items, enabling convenient and efficient transport.
We offer suggestions for improving the curved conveying environment, such as "curved belts have frayed edges and require a lot of maintenance" and "metal mesh belts generate metal powder and we want to avoid metal contact." - For details on the chain's features, please refer to the special page for the WTU3010T-KW type Plastic modular chain in the banner below.
■Applications
Below are the industries we recommend:
It may not be possible to use this product depending on the conveying capacity (conveyor speed), conveyed items (weight, shape), environment, application, etc.
Please use this as a guide when making your selection.
If you have any applications or conditions not listed, please contact us.
Recommended industry/carrying size (●: Recommended ○: Usable △: Varies depending on carrying conditions)
| Transport size (weight) |
Industry | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Can manufacturing | beverage | tire | Machine parts | logistics | Medicines | Bakery and Food | secondary battery | semiconductor· Solar panel related |
|
| large | △ | △ | △ | △ | △ | △ | △ | △ | △ |
| Medium | ○ | ○ | △ | ○ | ○ | ○ | ○ | ○ | ○ |
| Small | ● | ● | ○ | ● | ● | ● | ● | ● | ● |
Purpose
- ■Cardboard transport
- ■ Suitcase transportation
- ■ Tray transport
- ■ Canned drink transport
- ■Transporting PET bottled drinks
Product List
*Click on the format to display detailed information.
| Chain pitch mm | 30 | |
|---|---|---|
| Purpose | For curved transport | |
| Chain Type | Closed type | |
| - | ||
| Main body chain specifications | - | |
| Pin Type | - | |
| Pin Material | Special engineering plastics | stainless steel |
| Pin Shape | - | |
| Top plate thickness mm | - | |
| Pusher Material | - | |
| Other features | - | |
| Model | WTU3015T-K | WTU3015T-K-SUSP |
|
 |
|
| Chain width mm | 228.6～762.0 | |
| Organizational Unit | Every 76.2 mm | |
