Plastic Series Open type TKET (EasyTrax)
- Link
Shortening/lengthening
- Cable Carrier (CABLEVEYOR) has a highly convenient structure that integrates Tsubaki's unique spring-swivel arm and link.
- - Cables and hoses can be inserted quickly and efficiently without the need to open and close the arm.
- - Reduces the risk of the arm falling off the link.
Features
Two-tone molding integrates the opening and closing arm and link
Inner surface shape provides excellent protection for cables and hoses
Damper structure realizes low noise
Quick and easy cable/hose insertion
Lineup includes outer and inner opening/closing types
Vertical dividers can be installed
Cable Carrier (CABLEVEYOR) body is made of two different materials, and the opening/closing arms and links are integrated into one body through two-color molding.
strain relief combs cable
With clamp
Plastic Bracket
1. Spring swivel arm
The cable/hose is inserted by pushing it into the spring-loaded pivoting arm.
It is easier to insert additional material than the slit type.
The spring-loaded swivel arm allows for efficient storage of cables and hoses.
With a slit-type arm, the stored cables prevent additional insertion.
2. Spring swivel arm and link integrated
The spring-swivel arm and link of the TKET32H18 are made of different materials and integrated into one piece by two-part molding, which also helps prevent the arm from falling off or getting lost.
3. Link disconnection prevention function
The free span and bending sections have a structure that firmly connects the links, so high strength and rigidity are maintained even when Cable Carrier (CABLEVEYOR) is installed sideways.
Special specifications
Model number display example
| TKET | 32 | H18 | - | 30 | W38 | R48 | + | 20L | - | FOCL | - | MOCL |
| ｜ Variety symbol |
｜ pitch mm |
｜ Inner Height mm |
｜ ｜ ｜ ｜ |
｜ Inner width mm |
｜ bending radius mm |
｜ Number of links L |
｜ Brackets/Metal Fittings |
｜ Brackets/Metal Fittings |
||||
| Stay openable structure |
||||||||||||
Product List
*Click to display detailed information.
| Cables ・Hose Maximum Outer Diameter mm |
Inner Height mm |
Inner width mm |
bending radius mm |
Pitch mm |
Stay openable structure | |
|---|---|---|---|---|---|---|
| Outside openable stay type | Arm inner circumference opening and closing type | |||||
| 16 | 18 | 25 | 28 | 32 | TKET32H18-30W25R28 | TKET32H18-40W25R28 |
| 38 | TKET32H18-30W25R38 | TKET32H18-40W25R38 | ||||
| 48 | TKET32H18-30W25R48 | TKET32H18-40W25R48 | ||||
| 75 | TKET32H18-30W25R75 | TKET32H18-40W25R75 | ||||
| 100 | TKET32H18-30W25R100 | TKET32H18-40W25R100 | ||||
| 38 | 28 | TKET32H18-30W38R28 | TKET32H18-40W38R28 | |||
| 38 | TKET32H18-30W38R38 | TKET32H18-40W38R38 | ||||
| 48 | TKET32H18-30W38R48 | TKET32H18-40W38R48 | ||||
| 75 | TKET32H18-30W38R75 | TKET32H18-40W38R75 | ||||
| 100 | TKET32H18-30W38R100 | TKET32H18-40W38R100 | ||||
