The dust-proof and rust-proof jack is used for lifting devices in clean environments
Linipower Jack Ball screw type, etc.
overview
In the glass substrate stacking process on FPD (flat panel display) manufacturing lines, there was a demand for a device that was compatible with clean environments and capable of high-precision lifting on multiple axes.
By introducing Linipower Jack, which are compatible with special surface treatments and low-dust coatings, we have been able to suppress rust and dust generation from painted surfaces, enabling stable operation while maintaining a high level of cleanliness in a clean environment.
By using Tsubaki's comprehensive jack system selection service, which includes not only jacks but also couplings and gear motors, product selection and ordering processes became more efficient, contributing to a reduction in labor hours.
Problem
It was necessary to introduce a lifting device compatible with clean environments in the glass substrate stacking process on the FPD production line.
Additionally, as circuit boards become larger and more precise, it is necessary to link multiple axes to raise and lower them accurately, making it difficult to select the optimal overall equipment configuration.
Adopted products
リニパワージャッキ ボールネジタイプ
The JWB (Ball screw type) is a high-performance screw jack suitable for medium speed applications.
The main components are precision Ball screw and high-precision worm gears.
Designed for medium speed applications, the use of Ball screw provides high efficiency and a long life.
*This example is a special product that does not meet the standard specifications. Please contact us for details.
ECHT-FLEX Coupling NEF Series (Disc Coupling)
Boasting an extensive lineup, this is the definitive disc coupling.
FEMにて最適設計されたディスク形状により確実なトルク伝達、ミスアライメントの吸収等の機能に加え、
高精度な位置決めや無潤滑といった優れた特長を持ちます。
There are a wide variety of shaft fastening methods available, and environmentally resistant specifications are also available.
Torque range: 19.6 to 6860 N m / Applicable shaft diameter: Φ9 mm to Φ130 mm
Gear Motor TA/TR series
Parallel shaft helical gear reducer
The TA series (0.1 to 0.4kW) uses an aluminum frame motor and silent brake, making it small, lightweight, and quiet to operate.
TR series (0.75 - 2.2kW) is compatible with High Efficiency motors. (Premium Efficiency : IE3 )
Furthermore, we can also manufacture IoT specifications that integrate sensors and motors.
Miter Gear Box
High performance, high efficiency general-purpose spiral bevel gearbox with right-angle shaft.
It is a long-lasting product that has been used for a variety of purposes for over half a century since its release.
Thanks to our extensive track record and experience, we have earned a high reputation for our reliability from customers in a wide range of fields.
By using a spiral bevel gear, high transmission and high efficiency are achieved.
Benefits of adopting the product
Tsubaki's Linipower Jack are available with specially surface-treated screw shafts and ball nuts, as well as special coatings that suppress dust generation, preventing rust and deterioration of the coating and allowing them to be used safely in clean environments.
Furthermore, the jack system bulk selection service allowed the company to select not only jacks but also couplings and gear motors, all from Tsubaki, which enabled product selection and ordering to be handled all at once, reducing man-hours and streamlining procurement.
Tsubaki will do its utmost to support you in solving any problems you may have.
Please feel free to contact us with any concerns you may have.
Click here for details on the adopted products
Click here for consultation
