technical data Reducer Miter Bevel Gearbox Handling

This section describes general matters regarding handling.

For details, please refer to Instruction Manuals attached to the product.

1. Before Use

  • (1) Before installation, check that the specifications on the nameplate match your requirements.
    Note) In particular, check the oil gauge and the position of each plug to make sure that the mounting type matches, and also check the rotational relationship.
    (ED2, 4, and ARA Gear Box are grease lubricated and do not have an oil gauge.)
  • (2) Has the product been damaged during transportation?
  • (3) Are any of the bolts loose?

How to read the nameplate

How to read the nameplate
  • (1) TYPE (model number)
  • (2) RATIO (reduction ratio)
  • (3) MFG. No. (manufacturing number)
  • (4) DRAWING No.
