Brake-equipped motor option for Power Cylinder, common to U, T, and G series

A special brake-equipped motor is available as an option to accommodate a variety of environments and regions.

  • Heat resistance
  • waterproof
  • Inverter drive
  • Explosion-proof
  • High efficiency
  • Overseas Standards
  • Motor installation by customer

Model number display example

LP T C 4000 L 10 V T1 LJ - TK
｜
Series Name
(U.T.G.)		 ｜
Voltage Symbol		 ｜
｜		 ｜
*Please add -TK to the end.
Motor Options

Brake motor variations

motor Specification symbol Applicable capacity
(kW)		 Allowable ambient temperature
*1		 Heat resistance class
*2		 Percentage duty cycle
%ED		 Time rating For brakes
Power Supply		 Protection class
Standard (0.1~3.7kW) Heat resistance class B - 0.1～3.7 -15～40℃ B 25 S2 30min Built-in terminal box IP55
Standard (5.5~15kW) Heat resistance class B - 5.5～15 -15～40℃ B 25 S1 Built-in terminal box IP55
Heat resistance 40℃ F class Heat resistance class F T1 0.1～1.5 0～40℃ F 25 S2 30min Built-in terminal box IP55
Heat resistance 60℃ F class Heat resistance class F T2 0.1～1.5 0～60℃ F 15 S2 15min Separately placed*3 IP55
Heat resistance 80℃ F class Heat resistance class F T3 0.1～1.5 0～80℃ F 5 S2 5min Separately placed*3 IP55
Heat resistance 80℃ H class Heat resistance class H T4 0.1～1.5 0～80℃ H 15 S2 15min Separately placed*3 IP55
Protection class IP56 Meets waterproof requirements higher than the standard (IP55) W 0.1～1.5 -15～40℃ B 25 S2 30min Built-in terminal box IP56
Inverter drive Constant thrust operation possible in the range of 6 to 60Hz Z 0.1～1.5 0～40℃ F 25 S2 30min Built-in terminal box IP55
Explosion-proof Structural standard: d2G4 D 0.2～1.5 -10～40℃ B 25 S3 40% - IP44
High-efficiency motor Premium efficiency IE3 E 0.75～11 0～40℃ B 25 S1 Built-in terminal box IP55
CE marking Applicable standard: EN60034-1 N 0.1～0.4 -15～40℃ B 25 S2 30min Built-in terminal box IP55
UL standard compliant Applicable standard: UL1004
UL File No. E225995		 N2 0.1～0.4 -15～40℃ A 25 S2 30min Built-in terminal box IP20
CCC standard compliant National standard: GB12350 N3 0.1～0.4 -15～40℃ E 25 S2 30min Built-in terminal box IP55
Adapter Specifications Easy installation of customer-supplied motors
(Dimensions below)		 A 0.1～7.5 - - 25 - - -
  • *1 No condensation
  • *2 The brakes are heat-resistant class B.
  • *3 Install the power supply module in an environment below 40°C. The motor terminals are lug type and can withstand temperatures up to 80°C.
    Heat resistant up to 80°C. The power supply voltage for H-class power modules is 200 to 220V only.

For detailed information about motor options, click here

Motor basic specifications

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 3.7kW
  • - All outdoor specifications (IP55), with brakes
  • ・Heat resistance class B

Standard Voltage

・Voltage symbol: No symbol (200V class), V (400V class)

  • Usable temperature range: -15 to 40°C (no condensation)
  • Percentage duty cycle: 25%ED
  • Rating: S2 30min
  • Brake power supply module: Built-in terminal box

Notes

Please contact us if you plan to use the brake separately.

Different voltage compatible

・Voltage symbol: V1 (380V, 50Hz), V2 (380V, 60Hz), V3 (415V, 50Hz), V4 (460V, 60Hz)

Motor Variations

IP56 specification: W

High protection levels are often required for ship and port related equipment. This new model meets this requirement by complying with IP56 (dustproof and water resistant).

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 1.5kW
  • - All outdoor models, equipped with brakes
  • ・Heat resistance class (B)

IP56 motor compatible

・Model number: W (200V class), VW (400V class)

  • Usable temperature range: -15 to 40°C
  • Percentage duty cycle: 25%ED
  • Rating: S2 30min
  • Type: Fully sealed and air cooling type three-phase induction motor

Heat resistance: T

Compared to previous models, we have achieved a significant reduction in delivery and price. In addition, we are now able to meet heat resistance class "H," which was previously not possible.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 1.5kW (please consult us for larger capacities)
  • - All outdoor specifications (IP55), with brake (brake is heat resistant class B)

Heat resistance class "F" compliant

40℃

・Model number: T1 (200V class), VT1 (400V class), V1T1 (380V, 50Hz), V2T1 (380V, 60Hz), V3T1 (415V, 50Hz), V4T1 (460V, 60Hz)

  • Usable temperature range: 0 to 40°C (no condensation)
  • Percentage duty cycle: 25%ED
  • Rating: S2 30min
  • Brake power supply module: Built-in terminal box
60℃

・Model number: T2 (200V class), VT2 (400V class), V1T2 (380V, 50Hz), V2T2 (380V, 60Hz), V3T2 (415V, 50Hz), V4T2 (460V, 60Hz)

  • Usable temperature range: 0 to 60°C (no condensation)
  • Percentage duty cycle: 15%ED
  • Rating: S2 15min
  • Brake power module: Separate (standard DC rectifier)

    -Please install in an environment below 40°C.

    ・If you require a built-in terminal box, please contact us.

80℃

・Model number: T3 (200V class), VT3 (400V class), V1T3 (380V, 50Hz), V2T3 (380V, 60Hz), V3T3 (415V, 50Hz), V4T3 (460V, 60Hz)

  • Usable temperature range: 0 to 80°C (no condensation)
  • Percentage duty cycle: 5%ED
  • Rating: S2 5min
  • Brake power module: Separate (standard DC rectifier)

    -Please install in an environment below 40°C.

Notes

The motor terminals are lug type.

Heat resistance class "H" compatible

・Model number: T4 (200V class), VT4 (400V class), V1T4 (380V, 50Hz), V2T4 (380V, 60Hz), V3T4 (415V, 50Hz), V4T4 (460V, 60Hz)

  • Usable temperature range: 0 to 80°C (no condensation)
  • Brake power module: Separate (special DC rectifier)

    -Please install in an environment below 40°C.

    - The power supply voltage for the brake power module is 200 to 220V only.

Notes

The motor terminals are lug type.

IE3 motor specifications ：E

The brake motor used in the standard Power Cylinder is a short-time rated motor (S2).

Power cylinder must not need criteria for IE3 premium efficiency class, however, it can be equipment IE3 motor on customer request.

*Note: Please note that the motor size, wiring, and current value will change.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series
  • ・Applicable motor capacity: 0.75kW to 11kW
  • - All outdoor specifications (IP55), with brakes
  • - Usable temperature range: 0 to 40°C (no condensation)
  • ・Brake power supply module: Built-in terminal box

IE3 motor specifications

・Model number: E (200V class), VE (400V class)

Inverter specifications: Z

Compared to conventional models, we have achieved a significant reduction in product delivery and lower prices. Speed control, including acceleration/deceleration and variable speed, is now easy, improving the controllability of Power Cylinder.

In addition, the standard model comes with a brake and is suitable for outdoor use.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 1.5kW (higher capacity is also supported)
  • - All outdoor specifications (IP55), with brake (brake is heat resistant class B)
  • - Heat resistance class F
  • - Constant torque operation is possible in the range of 6 to 60 Hz.

Inverter drive compatible

・Model number: Z (200V class), ZV (400V class)

  • Usable temperature range: 0 to 40°C (no condensation)
  • Percentage duty cycle: 25%ED
  • Rating: S2 30min
  • Brake power supply module: Built-in terminal box

Notes

Apply normal power supply voltage, not inverter output, to the brake power supply module.
The applicable power supply voltage is 200 to 220V for the 200V class and 400 to 440V for the 400V class.

Global specification: N

Power Cylinder that comply with global directives, regulations, and systems (CE, UL, CCC) are now available.

It can be used for equipment exported overseas.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 0.4kW (higher capacity is also supported)
  • - Usable temperature range: -15 to 40°C (no condensation)
  • ・All with brakes

Notes

Only motors with brakes are compliant with the standard. If you require limit switches, etc., please contact us.

CE compliant

・Model number: N (200V class), VN (400V class)

・Specifications (both N and VN) Protection type: IP55
Heat resistance class: (B)

CE

Target directive standards

Target directive: Low Voltage Directive 2014/35/EU

Applicable standard: EN60034-1
(Motor regulations)

Products exported to Europe cannot be exported to the European market unless they bear the "CE mark," which certifies that they comply with the safety requirements stipulated in European EC directives. (CE compliance means that the "CE mark," which certifies compliance with EC directives, is affixed to the product itself.)

UL compliant

・Model number: N2 (230/240V, 60/60Hz), VN2 (460V, 60Hz)

・Specifications (both N2 and VN2) Protection type: IP20
Heat resistance class: (A)

UL

Target Directive Standard File No.

Applicable standard: UL1004

UL File No.：E225995

UL is an abbreviation for Underwriters Laboratories, which represents safety testing in the United States. (UL-compliant means that a motor that has been recognized and acquired by the UL standard is used, and the UL mark certifying UL standard is affixed to the product itself.)

The C-UR model is certified and complies with both UL and CSA standards.

CCC compatible

Model number: N3 (200/220/200/220V, 50/50/60/60Hz, 0.4kW is only available in 220/220V, 50/60Hz), VN3 (380V/50Hz)

・Specifications (both N3 and VN3) Protection type: IP55
Heat resistance class: (E)
*The value in parentheses varies depending on the motor capacity.

CCC

National standard: GB12350

CCC is a compulsory certification system in China, and in order to export small-output electric motors of 1.1kW or less to China, they must display the CCC mark, which certifies compulsory certification.

We have expanded into China and obtained certification from the China Quality Certification Center (CQC).

Explosion-proof specification: D

Power Cylinder with pressure-resistant explosion-proof construction that can be used in Class 1 and Class 2 hazardous locations are now available with Quick delivery.

A pressure-resistant explosion-proof structure is a structure that allows a container to withstand the pressure of an explosion of explosive gas inside the container and prevents the explosive gas from igniting outside.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.2kW to 1.5kW (higher capacity also supported)
  • - All outdoor specifications (IP44), with brakes
  • ・Heat resistance class B

d2G4 compatible

・Model number: D (200V class), VD (400V class)

  • Usable temperature range: -10 to 40°C (no condensation)
  • Percentage duty cycle: 25%ED
  • Rating: S3 40%
  • Brake power module: None (AC brake)

Notes

Two external stroke adjustment LSs (separate options) are also available to support pressure-resistant and explosion-proof specifications.
Please contact us separately.

Back to top of this page

Brake-equipped motor option code list

Motor Specifications Voltage and frequency
200/200/220V
50/60/60Hz		 400/400/440V
50/60/60Hz		 380V
50Hz		 380V
60Hz		 415V
50Hz		 460V
60Hz
standard No symbol V V1 V2 V3 V4
Heat resistance 40℃ F class T1 VT1 V1T1 V2T1 V3T1 V4T1
Heat resistance 60℃ F class T2 VT2 V1T2 V2T2 V3T2 V4T2
Heat resistance 80℃ F class T3 VT3 V1T3 V2T3 V3T3 V4T3
Heat resistance 80℃ H class T4 VT4 V1T4 V2T4 V3T4 V4T4
Protection class IP56 W VW - - - -
Inverter drive Z ZV - - - -
Explosion-proof D VD - - - -
High-efficiency motor E VE - - - -
Motor Specifications Voltage and frequency
200/200/220V
50/60/60Hz		 230/240V
60/60Hz		 200/220/200/220V
50/50/60/60Hz		 380/400/400/440V
50/50/60/60Hz		 460V
60Hz		 380V
50Hz
CE marking N - - VN - -
UL standard compliant - N2 - - VN2 -
CCC standard compliant - - N3 - - VN3
High efficiency and CE marking EN - - VEN - -
High efficiency and UL standard compliant - EN2 - - VEN2 -
High efficiency and CCC standard compliant - - EN3 - - VEN3
  • *For special brake-equipped motor specifications other than those listed above, the motor option symbol will be marked with "X".
  • *All models will be quoted on a case-by-case basis.

Adapter specification: A

If you have your own flange motor from a manufacturer of your choice, or one that conforms to IEC, NEMA, overseas standards, or other special specifications, we can even provide an adapter to make installation easy.

We can also accommodate special flange sizes and motor shaft diameters. Please contact us for details.

Common Specifications

  • ・Applicable models: Power Cylinder U series, T series, G series
  • ・Applicable motor capacity: 0.1kW to 7.5kW

Adapter Support

Model number: A (suitable for all motors with brakes)

・ Power Cylinder operating environment standards

  • Usable temperature range: -15 to 40°C (no condensation) *Temperatures above 40°C are also possible.
  • Percentage duty cycle: Within 25%ED

Notes

  • - When selecting a motor with a brake, ensure that the starting torque is 200% or more of the rated torque.
  • - For high efficiency, be sure to get Power Cylinder with a brake.
  • - Brake torque is 150% or more of the rated torque

Adapter Specifications

Adapter specifications and dimensions list

T Series Adapter Dimensions (IEC Standard Motor)

Unit: mm
Frame No. speed Motor Capacity Frame number AL AD AH AK B AJ S T U W Y Tap dia
LPTB
LPTC		 250 S 0.1 63 80 Φ160 - Φ110G7 4 Φ130 4Js9 12.8 Φ11F7 15 25 4-M8
L 0.1 72 - 5 14
M 0.2 -
H 0.4 71 - 5Js9 16.3 Φ14F7 32
LPTB
LPTC		 500 S 0.1 63 80 Φ160 - Φ110G7 4 Φ130 4Js9 12.8 Φ11F7 15 25 4-M8
L 0.2 72 - 5 14
M 0.4 71 - 5Js9 16.3 Φ14F7 32
H 0.75 80 92 Φ200 □170 Φ130H7 4 Φ165 6Js9 21.8 Φ19F7 20 42 4-M10
LPTB
LPTC		 1000 S 0.2 63 80 Φ160 - Φ110G7 4 Φ130 4Js9 12.8 Φ11F7 15 25 4-M8
L 0.4 71 72 - 5 5Js9 16.3 Φ14F7 14 32
M 0.75 80 92 Φ200 □170 Φ130H7 4 Φ165 6Js9 21.8 Φ19F7 20 42 4-M10
H 1.5 90L 8Js9 27.3 Φ24F7 52
LPTB
LPTC		 2000 S 0.4 71 85 Φ160 - Φ110G7 4 Φ130 5Js9 16.3 Φ14F7 15 32 4-M8
L 0.75 80 72 Φ200 - Φ130G7 5 Φ165 6Js9 21.8 Φ19F7 16 42 4-M10
M 1.5 90L - 8Js9 27.3 Φ24F7 52
H 2.2 100L 116 Φ250 □200 Φ180H7 4.5 Φ215 31.3 Φ28F7 20 62 4-M12
LPTB
LPTC		 4000 S 0.75 80 90 Φ200 - Φ130G7 4 Φ165 6Js9 21.8 Φ19F7 20 42 4-M10
L 1.5 90L 72 - 5 8Js9 27.3 Φ24F7 16 52
M 2.2 100L 116 Φ250 □200 Φ180H7 4.5 Φ215 31.3 Φ28F7 20 62 4-M12
H 3.7 112M
